Wholesale Price 640X480 Thermal with 2MP 30X Zoom Starlight Network Tethered Drone Camera
Our rewards are reduce selling prices,dynamic revenue team,specialized QC,sturdy factories,superior quality services for Wholesale Price 640X480 Thermal with 2MP 30X Zoom Starlight Network Tethered Drone Camera, Our enterprise warmly welcome close friends from everywhere in the environment to go to, examine and negotiate organization.
Our rewards are reduce selling prices,dynamic revenue team,specialized QC,sturdy factories,superior quality services for China Thermal Drone Camera and Block Camera, Must any of these goods be of interest to you, you should let us know. We are going to be satisfied to provide you a quotation on receipt of one’s detailed specifications. We’ve got our private experienced R&D enginners to meet any of one’s requriements, We appear forward to receiving your enquires soon’and hope to have the opportunity to work together with you in the future. Welcome to check out our company.
Application
UAV, Handheld Device, Security, Vehicle Device
Specification
| Technical Parameters | ||
| Performance feature | UV-THMGC38 | UV-THMGC64 |
| Detector Performance | ||
| Detector type | Uncooled amorphous silicon FPA | |
| FPA formal/pixel pitch | 384×288/17um | 640×480/17um |
| Sensitivity | ≤30mk at f/1.0 300K | |
| Frame rate | 50hz | 50hz |
| Spectral range | 8-14um | |
| Optical Performance | ||
| Lens(optional) | 17mm/19mm/25mm/35mm/40mm | |
| Image Processing | ||
| Non-uniformity correction | NST Self-adaption calibration | |
| Time to image | <6s | |
| Image enhancement | DDE | |
| Image display resolution | 768×576 | |
| Frame rate | 50HZ(PAL)/60Hz(NTSC) | |
| Display Control | ||
| Color | 9 pseudo color | |
| Polarity | white hot / black hot | |
| Image Reversal | Horizontal / Vertical | |
| Zoom | 1x-4x(0.05) | 1x-8x(0.1) |
| Manual Gain | YES | |
| Autol Gain | YES | |
| Rross Hair | YES | |
| Power | ||
| Operation Voltage range | DC:+2.5V—+5.5V | |
| Typical | 3.7V | |
| Power consumption | 0.7W | 0.9W |
| Reverse protection | YES | |
| Over / under voltage protection | YES | |
| Environmental Parameters | ||
| Operation temperature range | -40℃—-+60℃ | |
| Storage temperature range | -40℃—-+65℃ | |
| Humidity | 5%~95% | |
| Anti-Vibration and shock | GJB 150-16 2.3.1 | |
| GJB 150-18 T7 100g/6ms | ||
| Temperature shock | -5ºC/min(-40ºC—+60ºC) | |
| Physical Attributes | ||
| Weight (exclude lens) | ＜32g | ＜32g |
| Module size | 25mm*25mm*24mm | 25mm*25mm*24mm |
| control Interface | ||
| Communication | RS232 | |
| keyboard | 5keys | |
| Video Interface | ||
| Analogue Video | CVBS | |
| Ditigal Output | 16bit(50hz)/bt656/lvds/HDMI | |
Our rewards are reduce selling prices,dynamic revenue team,specialized QC,sturdy factories,superior quality services for Wholesale Price Sg-Uav2030nl-T25 640X480 Thermal with 2MP 30X Zoom Starlight Network Tethered Drone Camera, Our enterprise warmly welcome close friends from everywhere in the environment to go to, examine and negotiate organization.
Wholesale Price China Thermal Drone Camera and Block Camera, Must any of these goods be of interest to you, you should let us know. We are going to be satisfied to provide you a quotation on receipt of one’s detailed specifications. We’ve got our private experienced R&D enginners to meet any of one’s requriements, We appear forward to receiving your enquires soon’and hope to have the opportunity to work together with you in the future. Welcome to check out our company.
