PriceList for IP67 Vehicle IR Camera High Speed Dome Thermal Imaging PTZ Camera
Our mission will be to grow to be an innovative supplier of high-tech digital and communication devices by giving worth added design and style, world-class production, and service capabilities for PriceList for IP67 Vehicle IR Camera High Speed Dome Thermal Imaging PTZ Camera, Please ship us your specifications and demands, or truly feel totally free to get hold of us with any questions or inquiries that you may have.
Our mission will be to grow to be an innovative supplier of high-tech digital and communication devices by giving worth added design and style, world-class production, and service capabilities for China PTZ Camera, To win customers’ confidence, Best Source has set up a strong sales and after-sales team to offer the best product and service. Best Source abides by the idea of “Grow with customer” and philosophy of “Customer-oriented” to achieve cooperation of mutual trust and benefit. Best Source will always stand ready to cooperate with you. Let’s grow together!
Features
Close Loop PTZ structure, It can automatically return to its original position after being artificially rotated
Automatic wiper, Automatically activate wipers after sensing rain
IP67 waterproofing, It still works properly after being soaked in water
Excellent resistance low temperature, works well at -40°C enviroment
High Accuracy, Accurate positioning Angle
Specification
| Model No. | UV-DM789-2237/4237TH25 | UV-DM788-2146TH35 | UV-DM788-2172TH50 |
| Camera | |||
| Image Sensor | 1/1.8″ Progressive Scan CMOS | 1/2.8″ Progressive Scan CMOS | 1/2.8″ Progressive Scan CMOS |
| Effective Pixels | 1920(H) x 1080(V), 2 Megapixels;2560(H) x 1440(V), 4 Megapixels optional for 4237; | ||
| Minimum Illumination | Color:0.001 Lux @(F1.8,AGC ON); Black:0.0005Lux @(F1.8,AGC ON); | ||
| Lens | |||
| Focal Length | 6.5-240mm,37x optical zoom | 7-322mm;46x optical zoom | 7-504mm, 72x optical zoom |
| Aperture Range | F1.5-F4.8 | F1.8-F6.5 | F1.8-F6.5 |
| Field of View | H:60.38-2.09°(Wide-Tele) | H:42.0-1.0°(Wide-Tele) | H:41.55-0.69°(Wide-Tele) |
| Minimum Photographic Distance | 100-1500mm | 100-2500mm | |
| Zoom Speed | 5s | ||
| Thermal Camera | |||
| Detector | Camera 384×288/640×512 Vox detector | ||
| Pixel Size | Pixel Size 12μm | ||
| Lens | 25mm | 35mm | 50mm |
| NETD ≤40mK | ≤40mK | ||
| Spectral Range | Spectral Range 7.5～14μm, LWIR | ||
| PTZ | |||
| Pan Range | 360° endless | ||
| Pan Speed | 0.05°~200° /s | ||
| Tilt Range | -25°~90° | ||
| Tilt Speed | 0.05°~100°/s | ||
| Number of Preset | 255 | ||
| Patrol | 6 patrols, up to 18 presets per patrol | ||
| Pattern | 4 , with the total recording time not less than 10 mins | ||
| Power loss recovery | Support | ||
| IR LED (White-Light Optional) | |||
| Distance | Up to 150m | ||
| Video | |||
| Compression | H.265/H.264 / MJPEG | ||
| Streaming | 3 Streams | ||
| BLC | BLC / HLC / WDR(120dB) | ||
| White Balance | Auto, ATW, Indoor, Outdoor, Manual | ||
| Gain Control | Auto / Manual | ||
| Network | |||
| Ethernet | RJ-45 (10/100Base-T) | ||
| Interoperability | ONVIF(G/S/T) | ||
| General | |||
| Power | AC 24V, 50W(Max), PoE optional | ||
| Working temperature | -40℃ ~60℃ | ||
| Humidity | 90% or less | ||
| Protection level | Ip66, TVS 4000V Lightning protection, Surge protection | ||
| Mount option | Wall Mounting, Ceiling Mounting | ||
| Weight | 7.8kg | ||
| Dimension | 412.8*φ250mm | ||
Dimension
Our mission will be to grow to be an innovative supplier of high-tech digital and communication devices by giving worth added design and style, world-class production, and service capabilities for PriceList for IP67 Vehicle IR Camera High Speed Dome Thermal Imaging PTZ Camera, Please ship us your specifications and demands, or truly feel totally free to get hold of us with any questions or inquiries that you may have.
PriceList for China PTZ Camera, To win customers’ confidence, Best Source has set up a strong sales and after-sales team to offer the best product and service. Best Source abides by the idea of “Grow with customer” and philosophy of “Customer-oriented” to achieve cooperation of mutual trust and benefit. Best Source will always stand ready to cooperate with you. Let’s grow together!
