Product Description
- Start up at -20 ℃ , without additional warm-up components, no waiting.
- Large lighting angle, 2.0° -70 ° , no dead ends.
- Operating at -20 ℃ ~ 50 ℃ meet industrial standard.
- The life span is more than 50000 hours.
- The new laser homogenization technology, full-focus fill light even fine, no speckle.
- Military Standard Testing:
- Shock test (6 hours, 3 mm amplitude, frequency 25Hz);
- Drop test (with a package at 1.5 m height);
- Failure rate is within 5‰ after 48 hour aging test.
- Extreme temperature and lifetime assessment ( 6 months)
Specification
Parameters | Values and Description |
| Model | UV-LS500-VFXG |
| Lighting Distance | 500m |
| Wavelength | 850±10nm（940nm、980nm Optional） |
| Laser Chip Power | 2.2±0.3W |
| Output power | 2.0±0.3W· |
| Lighting Angles | Minimum Angle 2.0°; Lighting Distance >500m; Spot Diameter <36m;Near Angle 70°; Lighting Distance >40m |
| Working Voltage | DC12V±10% |
| Power Consumption | ＜11W |
| Control Mode | TTL232/485, Manual Optional |
| Communication Mode | UART_TTL |
| Communication Protocol | Pelco_D（Baud Rate 9600bps by default or 4800bps / 2400bps） |
| Storage Temperature | -20℃～+50℃ |
| Operating Temperature | -20℃～+50℃ |
| Dimension | 55mmx57mmx100mm |
| Weight | About 230g |
Product detail pictures:
