Lowest Price for China 2MP 33X Zoom Pelco Visca Network Lvds Dual Output Camera Module
We have now sophisticated machines. Our solutions are exported to the USA, the UK and so on, enjoying a great reward amid consumers for Lowest Price for China 2MP 33X Zoom Pelco Visca Network Lvds Dual Output Camera Module, We have been sincerely wanting forward to cooperate with consumers all over the earth. We feel we can easily satisfy with you. We also warmly welcome buyers to Visit our manufacturing unit and purchase our products and solutions.
We have now sophisticated machines. Our solutions are exported to the USA, the UK and so on, enjoying a great reward amid consumers forChina Lvds Output Camera,long range camera, With strong technical strength and advanced production equipment, and SMS people purposefully , qualified, dedicated spirit of enterprise. Enterprises took the lead through the ISO 9001:2008 international quality management system certification, CE certification EU ; CCC.SGS.CQC other related product certification. We look forward to reactivate our company connection.
Product Description
- Support 3A Control (Auto White Balance, Auto Exposure, Auto Focus)
- Support Backlight Compensation, Automatic Electronic Shutter, Adapt to Different Monitoring Environment
- Support 3D Digital Noise Reduction, High Light Suppression, Electronic Image Stabilization, 120dB Optical Width Dynamics
- Support 256G Micro SD/SDHC/SDXC
- Optional Interfaces for Convenient Function Expansion
- Small Size and Low Power, Easy to Inset PT Unit, PTZ
Application:
The 33x digital block camera module is based on 2MP Sony IMX328 CMOS sensor. It boasts the best performance for industrial and safety applications. Its 120 dB high dynamic range can deliver clear images even in different dark outdoor lighting condition. 33x digital camera can be used in crowded places, such as street, road, square, parking lot, supermarket, crossroads, GYM, station, etc.
It has multi interfaces and PTZ communication protocols that can meet the needs of various cameras. Our professional hardware R & D team can customize special interfaces according to the requirements of customers, and our software R & D team can customize the operation interfaces required by customers. Since we established, our company has served a variety of customers and provided countless customized services, all of these reflect the professionalism of our team.
Extremely strong compatibility and integrated features are the characteristics of UV-ZN2133D, which can be installed in most pan-tilt cameras without excessive integration operations
Solution
Advantages of laser night vision cameras
In recent years, more and more places need to be monitored 24 hours a day, especially at night, and especially in some special places, the concept of the entire survey is required. Passive infrared thermal imaging camera has the advantages of long range, high concept, ability to see through camouflage, smoke penetration, etc., but it also has disadvantages such as unclear image details and difficult to accurately identify. The existing domestic infrared LED lamp monitoring device The existence or concealment is poor, or the resolution is obviously insufficient, or the range of action is limited.
At present, the night vision technology that can truly achieve long-distance high-definition imaging is laser night vision technology. Laser lighting and CCD imaging technology are applied to night vision devices with laser-assisted light, which overcomes the limitation of traditional low-light-level night vision devices by illuminance. The hardware design and software programming of the control system and image processing have realized the automatic monitoring, tracking and alarm functions of the night vision device, and its range of action can reach several hundred meters to several kilometers.
High-definition laser camera, specially designed for the field of remote day and night monitoring, using active infrared laser as the illumination source, using high-resolution low-illuminance telephoto camera, capable of day and night
Continuous monitoring. At night, people, vehicles, facilities and other targets can be found as far away as 3000 meters.
The internal industrial-grade embedded control electronic system realizes the high stability control of the camera’s zoom, focus, video switching, and pan tilt/rotation. The overall shell is made of super aluminum alloy to achieve IP66 protection.
The protection level guarantees the long-term operation of the equipment in the harsh environment of the field.
Defog
The application scene of the fog penetration technology, which is specifically aimed at the air environment full of impurities such as water vapor, fog, haze, dust, rain and snow, and its purpose is to penetrate the impurities in the air to clearly obtain the remote monitoring objects Of the image. This is a way of cooperating with each other by means of optics, algorithms, etc., and automatically adjust the algorithm according to the image impurity concentration to achieve good correction of the picture, so as to obtain a clear image in sharp contrast with the real scene.
Fog penetration technology was initially promoted by scene applications such as border defense and coastal defense that are prone to fogging and require remote monitoring. Due to the lack of applications, only a small number of manufacturers have been promoting it for a long time. However, with the expansion of smog in mainland China, it has promoted all security manufacturers to study fog-permeable products.
Specifications
Specifications | ||
| Camera | Image Sensor | 1/2.8” Progressive Scan CMOS |
| Minimum Illumination | Color:0.001 Lux @ (F1.5,AGC ON); B/W:0.0005Lux @ (F1.5,AGC ON) | |
| Shutter | 1/25s to 1/100,000s;Supports delayed shutter | |
| Aperture | DC drive | |
| Day/Night Switch | ICR cut filter | |
| Digital zoom | 16x | |
| Lens | Focal Length | 5.5-180mm,33x Optical Zoom |
| Aperture Range | F1.5 - F4.0 | |
| Horizontal Field of View | 60.5-2.3°(wide-tele) | |
| Minimum Working Distance | 100mm-1500mm (wide-tele) | |
| Zoom Speed | Approximately 3.5s (optical, wide-tele) | |
| Compression Standard | Video Compression | H.265 / H.264 / MJPEG |
| H.265 Type | Main Profile | |
| H.264 Type | BaseLine Profile / Main Profile / High Profile | |
| Video Bitrate | 32 Kbps ~16Mbps | |
| Audio Compression | G.711a/G.711u/G.722.1/G.726/MP2L2/AAC/PCM | |
| Audio Bitrate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/16-64Kbps(AAC) | |
| Image(Maximum Resolution:1920*1080) | Main Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Third Stream | 50Hz: 25fps (704 x 576); 60Hz: 30fps (704 x 576) | |
| Image Settings | Saturation, Brightness, Contrast and Sharpness can be adjusted via the client-side or browser | |
| BLC | Support | |
| Exposure Mode | AE / Aperture Priority / Shutter Priority / Manual Exposure | |
| Focus Mode | Auto Focus / One Focus / Manual Focus / Semi - Auto Focus | |
| Area Exposure / Focus | Support | |
| Defog | Support | |
| Image Stabilization | Support | |
| Day/Night Switch | Automatic, manual, timing, alarm trigger | |
| 3D Noise Reduction | Support | |
| Picture Overlay Switch | Support BMP 24-bit image overlay, customized area | |
| Region of Interest | Support three streams and four fixed areas | |
| Network | Storage Function | Support Micro SD / SDHC / SDXC card (256G) offline local storage, NAS (NFS, SMB / CIFS support) |
| Protocols | TCP/IP,ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, SMTP, SNMP, IPv6 | |
| Interface Protocol | ONVIF(PROFILE S,PROFILE G) | |
| Smart Features | Smart Detection | Cross-border detection, area intrusion detection, entering / leaving area detection, hovering detection, personnel gathering detection, fast motion detection, parking detection / take detection, scene change detection, audio detection, virtual focus detection, face detection |
| Interface | External Interface | 36pin FFC (Network port, RS485, RS232, CVBS, SDHC, Alarm In/Out Line In/Out, power) LVDS |
| General | Working Temperature | -30℃~60℃, humidity≤95%(non-condensing) |
| Power supply | DC12V±25% | |
| Power consumption | 2.5W MAX (IR, 4.5W MAX) | |
| Dimensions | 97.5×61.5x50mm | |
| Weight | 268g | |
Dimension
We have now sophisticated machines. Our solutions are exported to the USA, the UK and so on, enjoying a great reward amid consumers for Lowest Price for China 2MP 33X Zoom Pelco Visca Network Lvds Dual Output Camera Module, We have been sincerely wanting forward to cooperate with consumers all over the earth. We feel we can easily satisfy with you. We also warmly welcome buyers to Visit our manufacturing unit and purchase our products and solutions.
Lowest Price forChina Lvds Output Camera,Long Range Camera, With strong technical strength and advanced production equipment, and SMS people purposefully , qualified, dedicated spirit of enterprise. Enterprises took the lead through the ISO 9001:2008 international quality management system certification, CE certification EU ; CCC.SGS.CQC other related product certification. We look forward to reactivate our company connection.
